Description

MAX (overflow sensor, 4-20mA)

MAX is a hanging sensor and is used to detect/alarming high level of liquid in the separator/settling tank. The sensor allows to distinguish liquid from the air, where the fluid can also be a liquid petroleum. Generating an alarm signal is formed by immersing the sensor in the liquid.

Technical Data

Supply voltage: 10V
Current consumption: 9mA – 15mA
Cable: Length 5 m, oil resistant, type: OZ-BL_2x0.75
Working temperature: -30°C ÷ +60°C
Ambient temperature: -30°C ÷ +60°C
Degree of protection: IP 68
Dimensions: Roller, fi 24mm, height 102mm
Mass with cable: 260 g
Mounting method: Vertical
Zone / ATEX Explosion Proof: Zone 0 / II 1G Ex ia IIB T4 Ga
ATEX compliant: EN 60079-0, EN 60079-11, EN 60079-26
EU examination certificate: KOMAG 18ATEX0262X
Intrinsic safety parameters of the power circuit: Ui = 13 V; Ii = 0,18 A; Ci ≈ 0,1; Li = 68 µH; Pi = 1,05 W
CE conformity: Directive EMC 2004/108/WE
EMC/immunity: PN-EN 50130-4:2012, PN-EN 61000-6-1:2008
EMC/ immunity: PN-EN 55022:2011, PN-EN 61000-6-
3:2008+A1:2012
