AlarmBoard – 8-channel LED alarm annunciator panel
AlarmBoard is an 8-channel annunciator panel designed for external indication of alarm conditions from SQUEALER/SQR controllers.
The alarm indicator panel enables monitoring of eight independent relay signals and provides clear LED visual and audible indication of alarm conditions.
The LED alarm panel is ideal for applications where fast and unambiguous notification of an alarm is required at a location outside the controller installation area. With eight NO/NC signal inputs, the device can be used with various relay contact configurations.
LED annunciator panel – key features
- 8 independent alarm indication channels
- LED visual alarm indication
- Built-in audible alarm indicator
- NO/NC input support
- Compatible with SQUEALER/SQR controllers
- 230 V AC power supply
- External alarm indication
- Compact design for vertical mounting
- Wide operating temperature range: -30°C to +60°C
8-channel LED alarm panel
AlarmBoard is equipped with 8 signal inputs, OUT1–OUT8, allowing eight independent alarm circuits to be monitored. Each channel can indicate the status of a relay output from the controller, providing clear identification of the source of the alarm.
When an alarm signal is triggered, the panel provides both LED visual indication and an audible signal, improving the visibility and audibility of the event.
230 V LED alarm indicator panel
AlarmBoard is powered by 230 V AC, making it suitable for use in standard electrical installations. The enclosure measures 200 × 120 × 57 mm and is designed for convenient vertical mounting.
The device is designed to operate in temperatures ranging from -30°C to +60°C, allowing the panel to be used in a wide range of environmental conditions.
Applications
The AlarmBoard LED alarm indicator panel is designed for installations requiring external, multi-channel indication of alarm conditions. It is primarily intended for use with SQUEALER/SQR controllers, while its eight relay signal inputs allow independent alarm signals to be monitored according to the supported input configuration.
Technical specifications
| Parameter | |
|---|---|
| Number of channels | 8 |
| Inputs | 8 × NO/NC |
| Indication | LED visual + audible |
| Power supply | 230 V AC |
| Dimensions | 200 × 120 × 57 mm |
| Weight | 460 g |
| Operating temperature | -30°C to +60°C |
| Mounting | Vertical |
AlarmBoard is an 8-channel LED alarm indicator panel designed for external alarm indication. The combination of visual LED and audible indication allows alarm events to be quickly noticed and the active alarm signal to be clearly identified.
